Geared Beam Trolley

Product Number: OZ1GBT

OZ Lifting

  • $339.52


Geared Beam Trolley

The Geared Beam Trolley is designed for the user who has a precision lift and needs the ability to move slowly across the beam with the least amount of sway, the precision ball bearing trolley wheels make it easy to maneuver heavy loads into position at any given point along the I, S, or W beam. The GBT has anti drop plates, double baked enamel paint, with individual test certs, and serial numbers for complete traceability.

Standards:
CE
Complies with portions of ASME 30.16

FEATURES and BENEFITS
  • Lightweight robust construction
  • Fits to most I, S, and W-Beams
  • Durable baked enamel paint protection
  • Gearing provides positive load positioning along the beam
  • Precision ball bearing trolley wheels
  • Anti-drop plate
  • Stainless steel ID tag
  • Individual test certificate & serial number
Product Specifications

(1, 2, 3, 5 and 10 tons)

PRODUCT CODE OZ1GBT OZ2GBT OZ3GBT OZ5GBT OZ10GBT
Safe working load (lbs) 2,000 (lbs) 4,000 (lbs) 6,000 (lbs) 10,000 (lbs) 20,000 (lbs)
Adjustable flange width (in) 2.57-8.00 (in) 3.46-8.00 (in) 4.01-8.00 (in) 4.49-8.00 (in) 4.92-8.00 (in)
A 15.56 (in) 15.63 (in) 17.69 (in) 18.25 (in) 18.75 (in)
Product dimensions (in) B 10.24 (in) 11.81 (in) 13.58 (in) 15.55 (in) 17.91 (in)
C 9.41 (in) 11.26 (in) 13.23 (in) 15.47 (in) 19.68 (in)
D 5.31 (in) 6.34 (in) 7.28 (in) 8.66 (in) 11.02 (in)
Minimum radius curve (ft) 3.28 (ft) 3.60 (ft) 4.26 (ft) 4.59 (ft) 5.57 (ft)
Net weight (lbs) 44 (lbs) 62 (lbs) 95 (lbs) 136 (lbs) 234 (lbs)
* Standard length of hand chain (ft) 9 (ft) 9 (ft) 9 (ft) 9 (ft) 9 (ft)

* Longer lengths available. Please contact the factory

(20 and 30 Ton)

PRODUCT CODE OZ20GBT OZ30GBT
Safe working load (lbs) 40,000 (lbs) 60,000 (lbs)
Adjustable flange width (in) 8.27-13.00 (in) **
A 25.48 (in) 25.48 (in)
Product dimensions (in) B 25.28 (in) 25.28 (in)
C 24.49 (in) 24.49 (in)
D 12.40 (in) 12.29 (in)
Minimum radius curve (ft) 14.76 (ft) 14.76 (ft)
Net weight (lbs) 565 (lbs) 573 (lbs)
* Standard length of hand chain (ft) 9 (ft) 9 (ft)

* Longer lengths available. Please contact the factory * Manufactured to customer’s requirements *50 Ton Available, please contact factory.

WHEEL DIMENSIONS (1, 2, 3, 5 and 10 tons)

WHEEL DIMENSIONS OZ1GBT OZ2GBT OZ3GBT OZ5GBT OZ10GBT OZ20GBT OZ30GBT
E 4.02 (in) 5.00 (in) 5.79 (in) 6.30 (in) 7.45 (in) 10.76 (in) 10.76 (in)
F 2.96 (in) 3.55 (in) 4.34 (in) 4.81 (in) 5.95 (in) 7.88 (in) 7.88 (in)

BAIL DIMENSIONS (1, 2, 3, 5 and 10 tons)

BAIL DIMENSIONS OZ1GBT OZ2GBT OZ3GBT OZ5GBT OZ10GBT OZ20GBT OZ30GBT
G 4.65 (in) 5.71 (in) 7.09 (in) 8.67 (in) 11.23 (in) 12.99 (in) 13.19 (in)
H 1.97 (in) 2.37 (in) 2.96 (in) 3.75 (in) 4.73 (in) 5.91 (in) 5.91 (in)
I 0.60 (in) 0.79 (in) 1.03 (in) 1.38 (in) 1.78 (in) 2.75 (in) 2.75 (in)
J 1.21 (in) 1.42 (in) 1.78 (in) 2.37 (in) 3.23 (in) 4.33 (in) 4.33 (in)
K 2.68 (in) 3.35 (in) 3.94 (in) 4.73 (in) 5.91 (in) 9.45 (in) 9.45 (in)
L 0.48 (in) 0.56 (in) 0.63 (in) 0.79 (in) 0.99 (in) 1.38 (in) 1.18 (in)
